| Description |
Fiber optics sensor |
| Mounting Type |
Can guide installation |
| Type |
Fiber optics sensor |
| Features |
Testing products |
| Model |
NPN PNP |
| light source |
4-element LED Body |
| Voltage – Supply |
DC 12~24V ±10% |
| Connection |
1 output port, wire lead type, wire length 2m |
| Light source |
Red LED (660nm) |
| Response frequency |
32Hz~20000Hz |
| Reaction time |
P-0 25us P-l 50us P-2 200μs P-3 400 us |
| Dielectric strength |
1000V AC at 50/60Hz for 1 min |
| Output Selection |
LIGHT-ON/DARK-ON (short press MODE to select) |
| Display Indicator |
Operation indicator: Red LED, dual digital monitor |
| Detection method |
Light intensity |
| Material |
Polycarbonate |
