This page details a vane-type flow sensor designed to monitor liquid coolants and other fluids in industrial machinery. It ensures equipment protection by detecting low or interrupted flow, helping to prevent overheating and damage. The sensor features a simple installation and a reliable electromechanical operation.
You can also complete the form for a bulk quote or to discuss OEM/ODM solutions. Our specialists will contact you promptly.
| Industry-specific attributes | |
| Media Type | fluid/water/oil/coolant and… |
| Flow Rate | 1~800DL/min |
| Other attributes | |
| Model Number | Digital |
| Whether the smart | Yes |
| Operating Temperature | 0~120℃(no icing) |
| Operating voltage range | 5~24 V(DC) |
| Operating temperature range | 0~120℃(no icing) |
| Operating humidity range | 35%~90%RH( no condensation) |
| Pulse output High level | > 4.3(DC)/5V input |
| Pulse output Low level | < 0.5(DC)/5V input |
| Flow–Pulse output | 1~800DL/min HZ F=4.5*Q(L/min) |
| rated voltage | 5V(DC) |
| Maximum Operating current | 15mA |
| load current | 10mA |
| Pulse output Duty Ratio | 50%±10% |
| Proof pressure | 1.75Mpa |
| Flow–Pulse output | 1～800DL/min HZ F=4.5*Q（L/min） |
| Pulse output rise time | 0.18 µs |
| Packaging and delivery | |
| Selling units | Single item |
| Single package size | 8X8X5 cm |
| Single gross weight | 1.000 kg |
