Safety scanner-2
| 320° Scan High-performance 2D Laser Radar | ||
| Model | NGA60N4 | NGA60N5 |
| Working range | 0.1m~6m（ ＠ 1.8%） | |
| 0.1m~10m（ ＠ 10%） | ||
| 0.1m~30m（ ＠ 90%） | ||
| Working angular | 320° | |
| Workking principle | PRT（pulse ranging technology） | |
| Laser class | Class 1（ IEC60825-1:2014） | |
| Laser wavelength | 905nm | |
| Pulse time | 5ns | |
| Sampling rate | 144 Khz | 432KHz |
| Scan frequency | 10Hz、20Hz | 15Hz、30Hz |
| Ambient light immunity | <100000 Lux | <80000 Lux |
| Measurement accuracy | ±20mm | |
| Repeatability | ±20mm | |
| Angular resolution | 0.025°，0.025°， 0.05° ，0.1° ，0.25°， 0.5° | |
| Measurement resolution | 1mm | |
| Power supply | DC 10V~30V | DC 15V~30V |
| Working current | 90 mA | 120 mA |
| Rated consumption | ＜3W | ＜3W |
| Interface | 3 NPN output signal or fault of red & orange area) |
4NPN input, 4 NPN output (output signal or fault of red & orange & yellow area) |
| Ethernet TCP/ UDP | ||
| Working indicator | Green | |
| Output indicator | Red, yellow, orange | |
| Ambient temperature | -10℃-55℃ | 25℃-50℃ |
| Ambient humidity | Less than 80%RH | |
| Storage temperature | -25℃-70℃ | |
| Mechanical protection | IP65 | |
| Wire port | Rj45 ethernet | |
| Material | Aluminum alloy (base) | |
| PUMA (Scanning window) | ||
| Sine vibration testing | 10Hz-1000Hz, 5g; 10 cycles for each axis (GBT2423.10-2019) | |
| Vibration resistance | 50-250Hz, RMS-42.4m/s2, 5h testing for each axis (GBT 2423.56-2018) | |
| Shock resistance | 50g, 3ms, 5000 times impacts on each axis；(G8T2423.5-2019) | |
| Product size | 60*60*83.5mm | 60*60*83.9mm |
| Cable length | 2m ethernet cable, 1.5m cable of power & IO | 1m ethernet cable, 1m cable of power & IO |
